Mimosa N5-X25 8 Pack

₨ 79,968.00

4.9-6.4 GHz Modular Twist-on Antenna
400mm Dish for C5x only
25 dBi gain – Contains 8 Antenna Assemblies

Description
Reviews (0)

Mimosa N5-X25 is a Dish antenna designed for use with the Mimosa C5xradio module. The antenna allows you to increase the native profit of the Mimosa C5x device to 25 dBi.

Product	N5-X25 (dish)
Gain	25 dBi
Polarization	Dual-slant 45°
Beamwidth, Symmetric (3 dB)	8°
Front-to-Back Ratio (min)	40 dB
Front-to-Side Ratio (min)	> 45 dB
Weight	0.98 kg (2.15 lbs)
Dimensions	Diameter: 429 mm (16.89”) Depth: 116 mm (4.57”)
Mount	Mimosa N5-X twist-on
Wind Survivability	200 km/h (125 mph)
Wind Loading	36.26 kg @ 160 km/h (79.95 lbs @ 100 mph)
