CBS350-24S-4G-EU

CBS350-24S-4G-EU MANAGED SWITCH

The Cisco Business 350 Series Managed Switches provide a portfolio of flexible, secure, and affordable solutions for small and medium-sized businesses. Available with a range of port counts and uplink options, these switches deliver enterprise-class features and simplified management via Cisco’s intuitive dashboard. Designed for high availability, scalability, and security, they support critical business applications, including VoIP, wireless, and surveillance, making them ideal for digital transformation in SMB networks.

Key Features

• 24 Gigabit SFP fiber ports plus 4 Gigabit SFP uplinks for high-speed, flexible fiber connectivity
• Managed Layer 3 switching with advanced static and multicast routing
• High switching capacity of 56 Gbps and forwarding rate of 41.66 million packets per second
• Fanless design for silent, energy-efficient operation and increased reliability
• Comprehensive security including IEEE 802.1X, ACLs, dynamic ARP inspection, and IP source guard
• Dual software images for seamless, zero-downtime firmware upgrades
• Industry-leading energy efficiency with IEEE 802.3az Energy Efficient Ethernet and cable-length power adjustment
• Robust QoS support optimizing voice, video, and data traffic
• Flexible management through web UI, CLI, and SNMP

SPECIFICATION OF CBS350-24S-4G-EU

PRODUCT DETAILS

• Brand: Cisco
• Series: Business 350 Series
• Model Number: CBS350-24S-4G-EU
• Product Type: Managed Layer 3 Gigabit Ethernet Switch (Fiber)
• Item Weight: 7 kg (5.95 lb)
• Product Dimensions: 440 x 203 x 44 mm (17.3 x 7.99 x 1.73 in)
• Color: White
• Manufacturer: Cisco

Technical Datasheet

PERFORMANCE

This switch operate at wire-speed with non-blocking architecture, delivering smooth data flow and minimal latency.It offers a switching capacity of up to 56 Gbps and a forwarding rate of 41.66 million packets per second. They support advanced Layer 2 and basic Layer 3 features, including IPv4/IPv6 static routing and multicast routing, ensuring efficient traffic handling and optimal network performance.

RELIABILITY

This switches features dual software images allowing seamless upgrades without network downtime, significantly enhancing network resilience. Fanless designs in several models reduce mechanical failure risk and noise, while robust protocols like Rapid Spanning Tree, Multiple Spanning Tree, and Link Aggregation Control Protocol (LACP) provide network redundancy and fast recovery from failures.

POWER CONSUMPTION

The switches support Energy Efficient Ethernet (IEEE 802.3az) to optimize power use by reducing consumption during low traffic periods. Power over Ethernet (PoE) models provide power budgets suitable for IP phones, cameras, and access points, with intelligent power management features like dynamic power allocation and automatic port power shutoff when links are down, contributing to overall energy savings.

ENERGY EFFICIENCY

It is embedded power-saving technologies manage power consumption dynamically based on link utilization and cable length. It comes with fanless designs and further reduce energy use and noise, aligning with sustainability goals. These energy-aware features minimize operational costs while maintaining network performance.

SECURITY FEATURES

It has security capabilities that include IEEE 802.1X port-based authentication, Access Control Lists (ACLs) for traffic filtering, Dynamic ARP Inspection, IP Source Guard, and BPDU Guard. These features protect against network attacks and unauthorized access. The switches also support Multidomain Authentication, guest VLANs, and MAC Authentication Bypass to enhance secure user access and policy enforcement.

ADDITIONAL FEATURES

This offers comprehensive Quality of Service (QoS) with multiple queues, traffic shaping, and prioritization to optimize voice and video traffic. Management is simplified with Cisco’s web UI, SNMP, CLI, and support for Cisco Configuration Professional. Features like Link Layer Discovery Protocol (LLDP), DHCP snooping, and sFlow provide enhanced network visibility and troubleshooting.

APPLICATION AREAS

The Cisco CBS350-24S-4G-EU switch finds applications in a variety of environments requiring reliable and high-performance fiber network connectivity for small and medium-sized businesses. It is ideally suited for office networks where high-speed, secure data transmission is essential. Educational institutions such as schools, colleges, and universities benefit from its scalability and advanced management features. Government offices leverage its robust security and network resilience capabilities. It also supports data centers needing Layer 3 routing and multicast traffic handling. Additionally, the switch is suitable for enterprise branch offices, healthcare facilities, and retail environments that require flexible deployment of fiber connectivity. Its fanless design makes it appropriate for noise-sensitive areas, and its managed features support seamless integration in industrial and IoT environments.

CONCLUSION

The Cisco CBS350-24S-4G-EU is an ideal fit as it delivers high performance and reliability with 24 Gigabit SFP ports and advanced Layer 3 switching capabilities. Its fanless design ensures quiet, energy-efficient operation, while comprehensive security features protect the network from threats. The switch supports seamless software upgrades with dual images, ensuring network uptime. Additionally, efficient power management and robust management options simplify deployment and maintenance. Backed by Cisco’s limited lifetime warranty and strong technical support, it offers a secure and scalable solution ideal for growing SMB networks.
