CBS220-24FP-4G-EU

Introduction

The Cisco CBS220-24FP-4G-EU 24-Port Gigabit Smart Switch is a powerful and reliable networking solution designed to meet the demands of growing businesses. With its comprehensive feature set, including 24 Gigabit Ethernet ports, 4 Gigabit SFP uplink ports, and full Power over Ethernet (PoE) support, this smart switch delivers exceptional performance and flexibility for various network environments.

Key Features

• 24 Gigabit Ethernet Ports: Provides ample connectivity for a wide range of devices, ensuring high-speed data transfer and network efficiency.
• 4 Gigabit SFP Uplink Ports: Offers additional flexibility for network expansion and high-bandwidth connectivity to other network devices.
• Full PoE Support: Delivers up to 370W of PoE power, ideal for powering IP cameras, phones, access points, and other PoE-enabled devices.
• Advanced Security: Features robust security protocols to protect your network from unauthorized access and threats.
• Easy Management: User-friendly web-based interface simplifies network configuration, monitoring, and troubleshooting.
• Compact and Rack-Mountable Design: Fits seamlessly into any network setup, with the option for rack-mount installation.

Benefits

Enhanced Network Performance

The Cisco CBS220-24FP-4G-EU switch ensures high-speed and reliable connectivity across all 24 Gigabit Ethernet ports. Its robust design and advanced features enhance overall network performance, making it an excellent choice for businesses looking to optimize their network infrastructure.

Flexible Network Expansion

With 4 Gigabit SFP uplink ports, this switch provides the flexibility needed for network expansion and integration with other high-bandwidth devices. Whether connecting to additional switches, servers, or other network components, the CBS220-24FP-4G-EU supports seamless scalability.

Power over Ethernet (PoE) Capabilities

The full PoE support with a total power budget of 370W allows for the direct powering of IP devices, eliminating the need for additional power supplies and cables. This feature simplifies installation and reduces overall infrastructure costs.

Comprehensive Security

Advanced security features, including network segmentation and access control, protect your network from potential threats. This ensures secure and reliable communication within your organization, safeguarding sensitive data.

Simplified Management

The intuitive web-based interface makes it easy to manage and configure the switch. This simplifies network administration, allowing for quick adjustments and troubleshooting to maintain optimal network performance.

Specifications

• Total Ports: 24 Gigabit Ethernet
• Uplink Ports: 4 Gigabit SFP
• PoE Power Budget: 370W
• Memory: 512MB
• CPU: 400 MHz ARM
• Flash Memory: 64MB
• Packet Buffer: 4.1 Mbit
• Dimensions: 440 x 203 x 44 mm
• Weight: 2.75 kg
• Power Consumption:
  • 110V: 16.3W
  • 220V: 16.34W
• Switching Capacity: 56 Gbps
• Forwarding Rate: 41.66 Mpps
• Operating Temperature: -20˚C to 70˚C
• MTBF: 1,049,371 Hours
• Warranty: Limited Lifetime

Conclusion

The Cisco CBS220-24FP-4G-EU 24-Port Gigabit Smart Switch is a versatile and powerful solution designed to enhance and optimize your network infrastructure. With its high-performance Gigabit ports, flexible SFP uplink options, full PoE support, and robust security features, it provides a reliable and efficient networking experience. Ideal for small to medium-sized businesses, this switch ensures seamless connectivity and simplifies network management, making it an excellent addition to any professional network setup.
