RB952Ui-5ac2nD-TC

RB952Ui-5ac2nD-TC

The hAP ac lite is a Dual-concurrent Access Point, that provides WiFi coverage for 2.4GHz and 5GHz frequencies at the same time.

Unit is equipped with a 650MHz CPU, 64MB RAM, five 10/100Mbps Ethernet ports (PoE output on port #5), dual-chain 802.11b/g/n 2.4GHz wireless, single chain 802.11a/n/ac 5GHz wireless, USB port for 3G/4G modem and a RouterOS L4 license.

The new design universal case allows the unit to be positioned either horizontally (desktop) or vertically (tower case). Wall anchored mounting kit is provided.

We have two versions available – RB952Ui-5ac2nD-TC (International) and RB952Ui-5ac2nD-TC-US (USA). RB952Ui-5ac2nD-TC-US (USA) is factory locked for 2412-2462MHz, 5170-5250MHz, and 5725-5835MHz frequencies. This lock can not be removed. RB952Ui-5ac2nD-TC (International) supports 2412-2484MHz and 5150MHz – 5875MHz range (Specific frequency range can be limited by country regulations).



Details
Product code	RB952Ui-5ac2nD-TC
Architecture	MIPSBE
CPU	QCA9531
CPU core count	1
CPU nominal frequency	650 MHz
Dimensions	34 x 119 x 98mm
RouterOS license	4
Operating System	RouterOS
Size of RAM	64 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 100’000 hours at 25C
Tested ambient temperature	-30°C to 70°C
Suggested price	$59.00

Wireless capabilities

Details
Wireless 2.4 GHz Max data rate	300 Mbit/s
Wireless 2.4 GHz number of chains	2
Wireless 2.4 GHz standards	802.11b/g/n
Antenna gain dBi for 2.4 GHz	1.5
Wireless 2.4 GHz chip model	QCA9531
Wireless 2.4 GHz generation	Wi-Fi 4
Wireless 5 GHz Max data rate	433 Mbit/s
Wireless 5 GHz number of chains	1
Wireless 5 GHz standards	802.11a/n/ac
Antenna gain dBi for 5 GHz	2
Wireless 5 GHz chip model	QCA9887
Wireless 5 GHz generation	Wi-Fi 5
WiFi speed	AC750

Ethernet

Details
10/100 Ethernet ports	5

MikroTik hAP ac lite Dual-concurrent Access Point (RB952Ui-5ac2nD-TC)

The MikroTik hAP ac lite is a versatile Dual-concurrent Access Point designed to provide comprehensive WiFi coverage across both 2.4GHz and 5GHz frequencies simultaneously. Equipped with a 650MHz CPU and 64MB of RAM, this unit ensures smooth and reliable network performance.

The hAP ac lite features five 10/100Mbps Ethernet ports, with PoE output on port #5, dual-chain 802.11b/g/n 2.4GHz wireless, single-chain 802.11a/n/ac 5GHz wireless, and a USB port for 3G/4G modem connectivity. It runs on RouterOS with an L4 license, offering robust network management capabilities.

Its innovative universal case design allows for flexible positioning, either horizontally (desktop) or vertically (tower case), and a wall-mounted kit is included for easy installation. Available in two versions—RB952Ui-5ac2nD-TC (International) and RB952Ui-5ac2nD-TC-US (USA)—the hAP ac lite caters to different regional frequency requirements. The USA version is factory locked to specific frequencies, while the International version supports a broader range.

Key Specifications of RB952Ui-5ac2nD-TC

Product Details

• Product Code: RB952Ui-5ac2nD-TC
• Architecture: MIPSBE
• CPU: QCA9531
• CPU Core Count: 1
• CPU Frequency: 650 MHz
• Dimensions: 34 x 119 x 98mm
• RouterOS License: 4
• Operating System: RouterOS
• RAM: 64 MB
• Storage Size: 16 MB FLASH
• MTBF: Approximately 100,000 hours at 25°C
• Tested Ambient Temperature: -30°C to 70°C
• Suggested Price: $59.00

Wireless Capabilities

• Wireless 2.4 GHz:
  • Max Data Rate: 300 Mbit/s
  • Number of Chains: 2
  • Standards: 802.11b/g/n
  • Antenna Gain: 1.5 dBi
  • Chip Model: QCA9531
  • Generation: Wi-Fi 4
• Wireless 5 GHz:
  • Max Data Rate: 433 Mbit/s
  • Number of Chains: 1
  • Standards: 802.11a/n/ac
  • Antenna Gain: 2 dBi
  • Chip Model: QCA9887
  • Generation: Wi-Fi 5
• WiFi Speed: AC750

Ethernet Ports

• 10/100 Ethernet Ports: 5

Conclusion

The MikroTik hAP ac lite is an excellent choice for those seeking a reliable and versatile access point that supports both 2.4GHz and 5GHz frequencies. Its robust features, flexible design, and affordable price make it an ideal addition to any network setup.
